Fortuna Spindle Repair
The Fortuna brand of spindles is designed and built with quality in mind. These rugged grinding spindles are used in[...]Continue Reading
The Fortuna brand of spindles is designed and built with quality in mind. These rugged grinding spindles are used in many applications and machines, and are the only spindle we use on our Kellenburger grinder machines.
If possible, we would like to have a piece of our customers tooling with every repair we do. It allows us to do a more comprehensive check on, not only the spindle, but also the influence the tooling mating surfaces may be having on the performance of the spindle.
Northland Tool brings over 30 years of experience to the table and we ensure every Fortuna spindle that goes out the door is done right. And we protect that with a 1-year warranty, which starts when your spindle is installed, not when we ship it.[...] Hide Details
Upon arrival, every spindle is logged into our production tracking software system. Any issues associated with incoming condition as related to transit are noted.[...]Continue Reading
The spindles are prioritized and moved to either the disassembly technicians or to the spindle run-up room, depending on the circumstances. Our techs carefully break down the spindle into its component parts while meticulously noting their general condition as well as specific damage to them. They also photograph the process and perform a full dimensional inspection to identify excessive wear which may help identify the cause of failure.
Once the initial disassembly and evaluation are completed, the spindle is given a second look by our production manager who reviews & completes the evaluation. He will identify the mode of failure and all pertinent issues, as well as recommended corrective actions. Many evaluations are not complete until the production manager consults with the head of our grinding & machining department. We often have recommendations for additional steps the customer can take to prevent premature spindle failure in the future. We call on our 30 plus years of experience rebuilding spindles to come to these conclusions.
After our purchasing department sources all replacement part costs & lead times, the quote is generated, given a final check and communicated to the customer for approval. Once we have received the approval, production is scheduled and parts are ordered. All spindle parts are carefully cleaned and any grinding or machining operations are completed. Only when all components are available and qualified does the spindle proceed to our spindle assembly technicians. These highly trained professionals assemble all the spindle components and then perform a rigorous break-in process which may include dynamic balancing as well as thermal & vibration analysis depending on the type of spindle. After a final quality control check is performed, the spindle is given back to our shipping department, carefully boxed to minimize the possibility of in-transit damage and shipped back to you, our customer. Hide Details
Fischer Fortuna FIV80R250.44 Spindle Repair
We have had this customer for over 20 years, but unfortunately our contact had retired. We introduced ourselves to the new contact and stayed in…
Fortuna FIV60R250.44 Spindle Repair
This Fortuna FIV60R250.44 spindle was sent to us with our customer indicating that the spindle was heating up and was hard to turn during operation. …
Does your spindle need repair? GET A QUOTE TODAY
MODELS WE REPAIR
At Northland, we take pride in our expert knowledge of every brand we repair-please see the list of models we repair below. If you do not see your particular model please contact us, we have probably repaired one just like it in our over 30 years of spindle rebuilding:
From coolant contamination to bearing failure to crashes, Northland knows that there are a variety of issues that will affect the performance of your spindle-and we’re prepared to handle them all. However, the common problems associated with this brand are:
- worn bearings
- bad o rings
- damaged screws
- taper runout
- crashed spindles
